The Model 65083H provides the weighing industry with the ultimate protection necessary for today’s hostile environments in an economical, low profile range suitable for platform scale manufacture.  Its low profile and fully welded sealing combined with high accuracy makes this load cell ideally suited for low profile platforms, pallet truck weighers, tanks and silos. The guide slots incorporated into the upper and lower =mounting faces enable manufacturers to easily position the load cell. Hermetically sealed against moisture, the construction of the model 65083H, in combination with a polyurethane dual shielded cable, enables continuous operation in demanding environments while maintaining a high operating specification. The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance, due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics.  FEATURES•    Rated capacities of 1000 to 10,000 pounds 500 kg to 5 metric tonnes•    Stainless steel, welded seal construction•    Interchangeable with Sensortronics model 65023 shear    beam•    Trade certified for NTEP Class III: 5000 Divisions and      Class IIIL: 10000 Divisions; OIML R60: 3000 Divisions •   Hermetically Sensorgage™ sealed to IP68 standards•   Cell Guard™ two year warranty •   Factory Mutual System Approved for Classes I, II, III;     Divisions 1 and 2; Groups A through G.     Also, non-incendive ratings (No barriers!) •    Optional -  Companion weigh module is Model 65080 Stainless     Steel TantaMount APPLICATIONS•   Hostile environments: Food and beverage processing Chemical and plastics                      processing Pharmaceutical and biomedical processing. •   Washdown and Clean-In-Place environments •   High performance weighing modules and assemblies

Read more less

Model 65114 is a high capacity, stainless steel single column compression load cell. This product is specifically designed for use in rugged outdoor environments. Made from stainless steel, IP67 welded sealing comes standard, with optional, fully hermetic, IP68 sealing available upon request. This load cell is used primarily in truck and train scales, but can just as easily be used to weigh tanks and silos. The load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments. The load cell is certified for Legal-for-Trade applications by both American NTEP and International OIML standards.  FEATURES • Rated capacities of 50,000 to 100,000 pounds; 25 to 50 metric tonnes • Stainless steel, welded seal construction • 30 feet standard cable length • Trade certified for NTEP Class IIIL: 10000 divisions and OIML R60 3000 divisions • Welded Sensorgage™ sealed to IP67 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. • Non-incendive ratings (without barriers) • Optional - Hermetically sealed version, meets IP66/68 standards  APPLICATIONS • Truck scales • Tank, bin, and hopper weighing

Read more less

Model 9103 is a double-ended, center-loaded shear beam type load cell constructed of stainless steel. This product is suitable for tank weighing systems, low-cost weighbridges and axle weighers. A reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area. A specially-designed mounting arrangement is available, providing the ideal solution for vessel/tank weighing. FEATURES • Capacities: 5k to 150k lbs • Low-profile construction• Stainless-steel construction• Certified to NTEP class IIIL, 10000 divisions• Sealing: IP67 (DIN 40.050)• Optional - FM Approved and ATEX & UKCA certified versions for use in potentially-explosive atmospheres  - EDOC option available; product appearance will differ from the photograph due to coating APPLICATIONS • Platform scales • On-board weighing • Weighbridges • Silo hopper weighing

Read more less

Model 9123 is a low-profile single-ended shear beam type load cell and is made from stainless steel. This load cell is suitable for small and medium platform scales, overhead track scales, hopper scales, and process weighing applications. Reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area. Ease of installation is made possible through the use of a partially-threaded hole to accept levelling feet, load buttons, or loading cables. FEATURES • Capacities: 500–5000 kg, 1k–20k lbs.• Low-profile construction• Certified to OIML R-60, 4000d and NTEP III,   5000 divisions• Sealing: IP67 (DIN 40.050)• Stainless-steel construction • Threaded load hole• Optional - FM certified for use in potentially explosive atmospheres APPLICATIONS • Low profile platforms• Pallet truck weighing• Tank and silo weighing

Read more less

The Model 92001 is an alloy steel single-point load cell designed for direct mounting in large platform scale applications. It has a very similar design to the Model 92006 with some key differences. The Model 92001 can register smaller loads but it requires different platform sizes depending on the desired capacity range. The cost effective load cell is ideal for use in counting, bench and floor scales. This model provides scale manufacturers with a high accuracy, low-cost sensor for their most demanding technical requirements. FEATURES • Capacity range: 50–1500 kg• Alloy steel construction• Single-point for the following platform sizes: - 50–750 kg: 600 × 600 mm platform - 1000–1250 kg: 750 × 750 mm platform - 1500 kg: 900 × 900 mm platform• Optional - Stainless steel construction  APPLICATIONS • Large platform scales• Bench and counting scales• Check weighing scales

Read more less

The Model 9903 is a double-ended beam-type loadcell with a low profile design, specifically designed for applications where space is limited or special mounting required. FEATURES • Capacities: 50k to 100k lbs• Stainless steel construction  APPLICATIONS • Hopper/silo/tank weighing • Weighbridges

Read more less

The Model ASC is a single column, stainless steel compression load cell. This product is suitable for use in road and rail weigh bridges and process weighing applications. The welded construction and built-in surge protection ensure that this product can be used successfully in harsh environments. This load cell meets the stringent Weights and Measures requirements throughout Europe and the USA FEATURES • Capacities: 30, 40, 50, and 60 t• Self-aligning, stainless steel single column• Hermetically sealed, IP66/IP68/IP69K• Certified for OIML R60 C6 and NTEP class IIIL 10000 divisions• Built-in surge protection tubes (GDTs)• Current calibration output (SC) ensures easy and accurate parallel connection of multiple load cells • Optional ❍ Digital version available (model DSC)  APPLICATIONS • Weighbridges• Silo hopper weighing

Read more less

The double-ended mounting provides good restraint for possible movement of the tanks and, in many cases, eliminates the need for check rods.  The shear beam design gives excellent performance for high capacity loading.  CLB is constructed of alloy steel and is fully potted with special chemical compounds to IP67 providing excellent protection against moisture and humidity. FEATURES •    Capacities 20k–125k lbs •    Free of horizontal movement •    Insensitive to side load •    Electroless nickel-plated alloy tool steel •    NTEP Class lllL 10000 approval from 20k lbs to 125k lbs•    Optional❍ FM approval available  APPLICATIONS •    Truck/rail scales •    Silo/hopper/tank weighing •    Fork-lift scales

Read more less

The Model CSP is a multi-column, low profile, stainless steel compression load cell. The unique four column design offers excellent insensitivity to eccentric loads while maintaining accuracy.  This product is suitable for use in road and rail weighbridges and process weighing applications. The fully leak-tested welded construction, advanced cable entry, and built-in surge protection tubes ensure that this product can be used successfully in demanding environments. This product meets the stringent Weights and Measures requirements throughout Europe. FEATURES • Capacities: 10–100 t• Low profile, multi-column stainless steel construction• Hermetically sealed, IP66, IP68, and IP69K• Certified to OIML R-60, 4000d and NTEP class IIIL10000 divisions- Model CSP offers klb capacity, imperial thread andNTEP approval- Model CSP-M offers metric capacity, thread and OIMLapproval• Built-in surge protection tubes (GDTs)• Current calibration output (SC version) ensures easyand accurate parallel connection of multiple load cells• Optional- ATEX and FM certified versions are available for use inpotentially explosive atmospheres- Multi-interval and multiple range versions available- Imperial capacities (25k, 50k, 100k, 200k lbs) notOIML approved APPLICATIONS • Truck and rail weighbridges• Silo and hopper weighing• Process weighing

Read more less

The Model DLB is designed to be center-mounted with double-linked loading. This design provides free movement in all horizontal directions virtually eliminating binding or friction points. The Shear Beam design gives excellent performance for high capacity loading.  The Model DLB is constructed of alloy steel and is fully potted and sealed with special compounds to IP67, providing excellent protection against moisture and humidity. FEATURES • Capacities 25k–125k lbs • Center-mounted with double-linked shear beam design • Free of horizontal movement • Insensitive to side load • Electroless nickel-plated alloy tool steel • NTEP Class lllL 10000 for whole series • Optional - Surge protection optional for 60k lbs  - FM approval available  APPLICATIONS • Truck/rail scales • Silo/hopper/tank weighing • Fork-lift scales

Read more less

Model DSR is constructed of alloy tool steel and is potted to IP67 providing excellent protection against moisture and humidity.  The double-ended mounting provides a good restraint to possible tank movements and, in many cases, eliminates the need for check rods.  The shear beam design gives an excellent performance for high capacity loading. The output is rationalized to facilitate multiple-cell applications. FEATURES • Capacities 1k–75k lbs• Double-ended center-load shear beam design• Rationalized outputs• Free of horizontal movement • Insensitive to side load• Electroless nickel-plated alloy tool steel • Optional - Hermetically sealed version  - Stainless steel version  - FM approval - EDOC product appearance will differ from the photograph due to coating APPLICATIONS• Silo/hopper/tank weighing

Read more less

The Model HBB is a single-ended bending beam load cell designed for multiple cell applications, such as low profile platform scales or small tank scales, when used with proper mounting accessories. It is insensitive to side load and capable of reversed loading. The Model HBB is constructed of stainless steel or alloy steel. The strainless steel version is hermetically-sealed to IP68, providing excellent protection against corrosive and wash-down environments. FEATURES • Capacities: 10, 20, 30, 50, 75, 100, 200 and 250 kg• Stainless steel or alloy steel construction• Stainless steel version hermetically-sealed• High side load tolerance• Easy installation• OIML C3 approval from 50 kg to 250 kg APPLICATIONS • Platform scales (multiple load cells)• Silo / hopper / tank weighing• Packaging machines• Dosing / filling• Belt scales / conveyor scales
