Model 380 is a very low-profile planar beam design, allowing direct mounting in low-profile platform scales. The range of capacities and low profile make Model 380 most suitable for use in a wide range of applications. FEATURES • Capacity range: 7.5–250 kg • Only 2.5–8 mm high • Very low profile • Aluminum construction • OIML R60 and NTEP approved.• IP65 protection • 1000Ω input impedance • Provides freedom in rectangular scale size design • Matched output and current calibration circuitry OPTIONAL• ATEX and UKCA certification available for potentially explosive atmospheres. APPLICATIONS • Personal scales • Commonly used in low-profile infant and adult medical scales • Large and medium low-profile platform scales • Airport baggage scales • Postal scales

Read more less

Model 5103 transducers are double-ended, center-loaded shear beam load cells and are constructed of nickel plated alloy steel. These products are suitable for tank weighing systems, low-cost weighbridges, and axle weighers. A reliable sealing is ensured by the proprietary TRANSEAL potting compound and additional mechanical protection of the strain gage area. A specially-designed mounting arrangement is available, providing the ideal solution for vessel / tank weighing. FEATURES • Capacities: 5k to 250k lbs• Low-profile construction• Nickel-plated alloy steel construction• Certified to OIML R60 3000d, NTEP CoC—10000d• Sealing: IP67 (DIN 40.050) • Optional - FM approved for use in hazardous locations  - ATEX & UKCA versions for use in potentially-explosive atmospheres - EDOC product appearance will differ from the photograph due to coating APPLICATIONS • Platform scales• On-board weighing• Weighbridges • Silo hopper weighing

Read more less

The Model 5203 is a double-ended shear beam type load cell. A reliable sealing and mechanical protection of the strain gage area is ensured by the use of potting compound with a metal cover. The center-loaded design results in minimal sensitivity to off-center forces. FEATURES • Capacities: 1k to 75k lbs • Environmental protection: IP67 (DIN 40.050)• Material: nickel-plated steel• Center-loaded design • Optional - FM certified versions are available for use in potentially explosive atmospheres APPLICATIONS • Silo, tank, hopper weighing• Custom system designs• Low capacity vehicle scales

Read more less

The Model 60001 is a tension-compression load cell with a humidity-resistant coating and shielded cables, which enable its use in harsh environments while maintaining operating specifications. Additional sense wires compensate for changes in lead resistance due to temperature change and/or cable extension. Ideally suited for lever conversions, hanging scales, force measurement and a wide range of other industrial applications. Nickel-plated for outstanding corrosion resistance. FEATURES • Rated capacities of 25 to 20,000 pounds, 50 kilograms to 10 metric tonnes • Designed for single or multiple load cell applications • Constructed of high quality alloy tool steel• Nickel plated for outstanding corrosion resistance • Sensorgage™ sealed to IP67 standards• Trade certified for NTEP Class III: 5000d, IIIL: 10000d and OIML R-60 3000d available • Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. Also, non-incendive ratings (No barriers!). • Optional - Stainless steel version is Model 60050 - EDOC option available; product appearance will differ from the photograph due to coating APPLICATIONS • Tank, bin and hopper weighing • Level and inventory monitoring• Truck scale conversions • Tension and compression measurements

Read more less

Model 60051 is a low profile high precision, stainless steel, single point platform load cell. The product’s low profile makes it ideal for many low to mid-range capacity weighing applications where space is at a premium. This load cell is most commonly used in platform scales, but can be adapted for use in many process weighing applications. The stainless steel construction and IP67 rating make this load cell ideal for any environmental installation. This load cell is specifically designed for use in corrosive and wet environments that are not appropriate for common aluminum load cells. This product is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments.  FEATURES • Rated capacities of 10 to 200 pounds • Stainless steel construction • Moment-compensated design for minimal sensitivity to moments induced by off-center loading • Sensorgage™ sealed to IP67 standards • Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. • Non-incendive ratings (without barriers) APPLICATIONS • Single-point platform scales • Bench, counting and deli scales • Checkweighing scales • Hopper scales and netweighing

Read more less

The Model 60058 is a mid to high capacity nickel-plated alloy steel, double-ended shear beam load cell. This product is designed for use in industrial and out door environments. Nickel plated steel construction limits corrosion from outdoor use. The IP67 sealing makes it suitable for applications that are subject to high-pressure wash down. Tank weighing is made simple when this load cell is combined with the EZ mount mounting hardware it was designed for. Its high accuracy and availability in high capacities make it ideal for certified truck and rail scales. This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments. This load cell is certified for Legal For Trade applications by the American NTEP standards. FEATURES • Rated capacities of 5,000 to 100,000 pounds, 2.3 to 45 metric tonnes • High quality alloy tool steel construction • Nickel plated for outstanding corrosion resistance • Replacement for RTI model 5103 (EZM1) • Integral conduit adaptor • Sensorgage™ sealed to IP67 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. Also, non-incendive ratings (No barriers!) • Optional - EDOC option available; product appearance will differ from the photograph due to coating APPLICATIONS • Tank, bin, and silo weighing • Railroad track scales • Truck scales

Read more less

Model 60060 is a single point load cell designed for direct mounting of large platforms. The product is a cost-effective load cell for use on counting, weighing, bench or floor scale products. This high accuracy load cell is approved to OIML R60, NTEP and other stringent approval standards. Suitable for use in hazardous environments, these load cells are FM approved to Class I, II, III, Division 1 and 2. A special humidity-resistant protective coating assures long term stability over the entire compensated temperature range. Two additional sense wires, sample the bridge supply voltage at the load cell. Complete compensation of change in the lead wires resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics. FEATURES • Rated capacities of 100 to 2000 pounds • Unique shear beam design—aluminum construction• Moment-compensated design for minimal sensitivity to moments induced by off-center loading • Ideal for situations exceeding the capabilities of similar “brick” design load cells • Trade certiied for NTEP Class III:5000 divisions; Class IIIL:10000 divisions and OIML R60 3000 divisions • Sensorgage™ sealed to IP67 standards • Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. • Non-incendive ratings (without barriers)• Available in stainless steel APPLICATIONS • Single-point platform scales • Belt conveyor scales • Bench and counting scales • Checkweighing scales • Hopper scales and netweighing

Read more less

The Model 60063 is a stainless steel S-Type load cell. Its welded sealing, combined with high accuracy, make this load cell ideally suited for a wide range of applications of process weighing and force measurement.  Approvals included NTEP III 5000d single and NTEP IIIL10000d multiple. Also available are versions approved for hazardous areas - FM I, II, III Division 1. FEATURES • Rated capacities of 500 to 20,000 pounds • Stainless steel, welded seal construction • Integrated loading brackets • Compatible with TCM tension mounting hardware • Designed for single or multiple load cell applications • Trade certified for NTEP Class IIIL: 10000d and III: 5000d • Sensorgage™ sealed to IP68 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. Also, non-incendive ratings (No barriers!)• Optional  - Mounting and loading accessory hardware available  APPLICATIONS • Hostile environments: Food and beverage processing Chemical and plastics processing Pharmaceutical and biomedical • Bin, hopper and belt conveyor scales • Level and inventory monitoring • Tension and compression measurements

Read more less

Model 620 is a stainless-steel S-type load cell. Its welded sealing combined with high accuracy, make this load cell ideally suited for a wide range of applications of process weighing and force measurements. Approvals include OIML C3 (3000d); NTEP 3000d single and NTEP 5000d multiple. The six-wire cable includes two sense wires that compensate for changes in lead resistance due to temperature changes and cable extension. Model 620 offers a choice of bolt threads in metric or unified systems; see table below.

Read more less

Model 65016-W is designed to be center-mounted with double-linked loading. This design provides free movement in all horizontal directions, virtually eliminating binding or friction points. The double Shear Beam design gives an excellent performance for high capacity loading.  The stainless-steel construction and IP67 rating make this load cell ideal for any environmental installation. FEATURES • Rated capacities of 1000 to 100,000 pounds • Stainless steel, welded seal construction • Insensitive to side loads and bending moments • High output—well suited to high deadload/low liveload applications • Load cells have matched outputs for multi-cell systems • Integral conduit adaptor• Sensorgage™ sealed to IP67 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G.• Non-incendive ratings (without barriers)• Optional  - Fully hermetically sealed version APPLICATIONS • Hostile environments:    Food and beverage processing    Chemical and plastics processing Pharmaceutical and biomedical processing • Tank, bin, and silo weighing • Batching, blending and mixing systems • Level and inventory monitoring

Read more less

Model 65040W is a mid to high-capacity welded stainless-steel, double-ended shear beam load cell. The product is designed for use in certified truck and rail scales and is available in capacities ranging from 25k through 75k lbs. (For higher capacities consult with the factory.)  This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially-explosive environments. This load cell is certified for Legal for Trade applications by American NTEP standards. FEATURES • Rated capacities of 25,000 to 75,000 lbs. (Higher capacities are also available)• Welded seal, stainless-steel construction • Center supported, external pivot loading• Integral conduit adaptor • Trade certified for NTEP Class IIIL: 10000 divisions • Sensorgage™ sealed to IP68 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. • Non-incendive ratings (without barriers) APPLICATIONS • Hostile environments:   Food and beverage processing   Chemical and plastics processing   Pharmaceutical and biomedical processing • Truck scales • Railroad track scales

Read more less

The Model 65058 is a mid to high capacity, nickel-plated alloy steel, double ended Shear beam load cell. This product is designed for use in certified truck and rail scales and is available in capacities ranging from 10,000 to 250,000 lbs. This load cell is rated intrinsically safe by the Factory Mutual System (FM); making it suitable for use in potentially explosive environments. This load cell is certified for legal for trade applications by both American NTEP and International OIML standards. FEATURES • Rated capacities of 10,000 to 225,000 lbs• Center-link loaded• Integral conduit adaptor• Trade certified for NTEP Class IIIL: 10000 divisions; Class III: 5000 divisions and OIML R60 3000 divisions in 20,000 to 100,000 lbs range• Sensorgage™ sealed to IP67 standards• Factory Mutual System Approved for Classes I, II, III; Divisions 1 and 2; Groups A through G. Also, non-incendive ratings (No barriers!).• Optional - EDOC (Electrodeposited organic coating): product appearance will differ from the photograph due to coating - 65058S stainless steel, welded seal version available - 65058-TSA companion assemblies for vehicle scales - 65069-TWA companion assemblies for vessel weighing APPLICATIONS • Truck scales• Railroad track scales• Precision tank, bin and silo weighing• Level and inventory monitoring
