Model 1042 Tedea-Huntleigh Low Profile Aluminum Load Cell
- Tedea-Huntleigh
Model 1042 Tedea-Huntleigh Low Profile Aluminum Load Cell
- Tedea-Huntleigh
Description
Title :- Model 1042 Tedea-Huntleigh Low Profile Aluminum Load Cell
Brand :- Tedea-Huntleigh
DESCRIPTION
The Model 1042 is a low profile single-point load cell designed for direct mounting in weighing platforms. Its small physical size, combined with high accuracy and low cost, makes this load cell ideally suited for retail, bench and counting scales.
With capacities starting at 5 kg and higher, the Model 1042 is crafted from anodized aluminum, ensuring durability and reliability. This high-accuracy load cell has been rigorously approved to NTEP and other stringent standards, including OIML R60, giving you the peace of mind that your measurements are precise and trustworthy.
But it doesn't stop there. The Model 1042 features a humidity-resistant protective coating, ensuring long-term stability across a wide temperature range. You can trust that it will perform flawlessly, no matter the conditions.
The innovative design includes two additional sense wires feed back the voltage reaching the load cell. Complete compensation of changes in lead resistance due to temperature change and/or cable extensions , is achieved by feeding this voltage into the appropriate electronics.
Features You’ll Love:
-
Capacities 1–200 kg
-
Sturdy aluminum construction
-
Compatible with single-point platforms up to 400 x 400 mm
-
OIML R60 and NTEP approved
-
IP66 protection
-
Available with metric and UNC threads
-
Optional
❍ ATEX, FM, and IECEx approvals available
❍ High stiffness version available for dynamic weighingPerfect for These Applications:
- Bench scales
- Counting scales
- Grocery scales
Specifications
- Weight: 200gr
- Usage: Indoor & outdoor
