High-Capacity, Versatile Load Cell for Precision Testing Applications The 22000kg Load Cell – Model 98001 is a universal low-profile alloy... Read more

Shipped today? Order within: Oct 12, 2025 23:59:00 +1100

Free shipping on all orders above 50,00

No hassle returns, 30 days return

Pay whenever you want

Easily pay within 30 days after you have received your package.
Read more

Description

High-Capacity, Versatile Load Cell for Precision Testing Applications

The 22000kg Load Cell – Model 98001 is a universal low-profile alloy steel shear beam load cell designed for applications that require both tension and compression loading, making it ideal for testing machines and heavy-duty industrial applications. Built for durability and precision, this load cell delivers reliable and accurate measurements even under demanding conditions.
Download Data Sheet

Key Features & Benefits:

Capacity: 22,000 kg (available in 0.5–100 t variants)
Construction: Alloy steel with nickel-plated finish for maximum durability and corrosion resistance
Universal Design: Supports both tension and compression loading for versatile applications
Cable Length: 6 m – flexible installation options
Loading Thread: MT – easy and secure mounting
Output: 2.0 mV/V – provides consistent signal for accurate measurements
Environmental Protection: IP67 rated for dust-tight and water-resistant operation
Precision Engineering: Ideal for testing machines, heavy industrial scales, and high-capacity weighing

Applications:

Testing machines requiring tension and compression loading
Heavy-duty industrial weighing systems
High-capacity process and platform scales

Limitations:

Not ATEX/FM approved – unsuitable for explosive or hazardous environments

Smart Tip: The Model 98001 is perfect for industrial setups demanding a versatile, high-capacity load cell capable of handling both tension and compression.

Description

The Model 98001 is a universal alloy steel shear beam load cell ideal for testing machine applications employing both tension and compression loading.

This shear beam design load cell provides excellent immunity to impact and side forces. This load cell includes integrated overload protection for compression loading applications.

Features

Capacity: 0.5–100 t
Alloy steel construction
Universal load cell
Integrated overload protection (in compression)
Tension and compression loading

Options

Model 98005 without base mounting plate (for compression applications only)
Metric and imperial threads

Parameter	Value	Unit
Rated capacity (kg)	500, 1k, 2k, 3k, 5k, 10k, 15k, 20k, 25k, 30k, 40k, 50k, 60k, 100k	kg
Rated output R.O	2.0	mV/V
Rated output tolerance	10	±%mV/V
Zero balance	1	±%FSO
Non-repeatability	<0.020	±%FSO
Creep error	<0.002	±%FSO
Ultimate over load	300	% of R.C
Excitation voltage	10	VDC or VAC RMS
Max. excitation voltage	15	VDC or VAC RMS
Input resistance	699–750	Ω
Output resistance	699–750	Ω
Insulation resistance	>1000	MΩ
Environmental protection	IP67

FSO - Full Scale Output
All specifications subjects to change whithout notice.

Application

Universal testing machines

Specifications

Weight: 200gr
Usage: Indoor & outdoor
